Product overview

• Suitable to adopt fixed frequency working mode, with powerful anti-jamming ability;?Effective reading range up to 80m (depend on reader and antenna, software configurable);?Super wide working band design, conforming to relevant industry rules and also flexible in application development;?Multi-Tag reading at the same time (more than 100pcs per second), no limitation or interference by tag quantity in the reading range.?Ultra-low power consumption，average working current<10uA

Product parameters

• Model No?MR3840T
• Type?2.4G Card type (Beacon type, MAX RF power)
• Inductive mode?Initiative transmit, RF Power-6dBm transmit every second
• Material?ABS, heat resistant ,White color
• Dimension?86*55*4mm
• Battery?battery life up to 3 years
• IP Grade?IP67
• Installation?Carry on
• Signal modulation?GFSK
• Communication speed?1Mbit/s
• Operation frequency?2.44GHz
• Output power?-6dbm
• Quiescent current?<3uA
• Peak current?<15mA
• Average current?3 years
• 2.4G RF Feature : Electrical Feature：?Environmental Feature:
• Operating temperature?-20℃~+45℃
• Storage temperature?-30℃~+65℃
• Operating humidity?<85%
